Moving Bridge & Nesting
Table CNC Machining Center
■ Centralized automatic lubrication system.
■ Centralized dust collection control system.
■ Tool automatic compensation system.
■ Automatic backlash preloading mechanism.
■ Heat exchanger cooling electric control box.
■ High rigidity design.
■ Taiwan PMI ball screw and rail guide.
■ Taiwan YUAN YI CHANG precise spiral rack transmission.
■ Italy HSD auto tool changing high frequency spindle.
■ Japan YASKAWA servo motor and driver.
■ Taiwan LIMING planetary type reducer.
■ Carousel type Plastic Steel tool changer with 8 tools.
■ Taiwan SYNTEC-PC control system.
■ Taiwan 9 vertical pneumatic line boring head
■ Italy OSAI-PC controller system. (Option)
■ Configuring fast automatic plate positioning and labeling via the arm to complete the work of each labeling operation.
■ Configuring dynamic vacuum suction arm, matched the vacuum cups over 250mm.
■ Automatic loading and unloading mechanism. Sticking label at prozone, while cutting and drilling happened at pro-zone.
■ Suitable for processing display counters, artificial stone flow management units, petrochemical PF filter plates, headboard, insulation plates, styrofoam model, yacht bedroom, OA office desktop.
